12S 13S 14S 15S 36V 48V 58.8V smart Bluetooth BMS with 20A to 60A constant discharge current with UART and RS485 communication

$6.90$47.80

1) Application:this smart BMS can work for 12S to 15S Lithium ion or Lifepo4 Battery with UART communication ,if client need the dual communication type , please click here :>12S 13S 14S 15S 36V 48V 58.8V smart Bluetooth BMS with 20A 30A 40A to 60A constant discharge current with UART and RS485 Dual communication

client can choose based on your battery chemistry features
2) Current : constant current of this version BMS can be made with 20A to 60A in accoridng to the different demand
3) Dimension: :Max 140*60*10mm (for less than 30A current ,and Max140*60*15mm for more than 30A Current

4) Our BMS will include a free connection cable with connector and with a Bluetooth Communication module . client can choose the PC Communication module separately based on your demand by selecting it from the dropdown list
4) Functions : except basic protection function , this BMS has ON/OFF switch ,PC and APP communication function.
5) Communication type :UART and RS485
6) We will ship out within 4~5 working days as we promised in according to client selected shipment methods strictly for few pcs sample orders , we will advise buyer the tracking number once it has been shipped , please know it kindly in advance
Clear

Description

Notes:all of our Smart BMS with Bluetooth function will equip a Bluetooth Communication module only , and buyer can choose the PC communication Module separately if needs ,please know it kindly in advance ,all orders will be dispatched within 4~5 days without problems .

We have Dual Communication type also available for selection hereby with RS485 and UART communication

1) Characteristics : this is a smart BMS with Bluetooth and PC communication which will be used to protect and monitor your battery status visible from the computer and your android APP phone .
discharge current and charging current .the charge and discharge port is same . Size :Max 140*60*10mm or 140*60*15mm
2) Protection functions :
This BMS has applied with high quality IC chip specially for lithium battery protection purpose .highly detection
precision degree on over-charge,over-discharge,voltage balancing ,and with detection on wires disconnection functions,
with three layers of over-discharge and over-current detections and delay times in detecting process.( Over-current 1,
over current 2,short cicircuit protection ) . short-circuit of charging port ,with two layers protection against over-voltage when charging :
3) With Mobile phone operation software systme to manage the detecting the battery working status and some parameters
setting . also this board can be available for the PC operation and Parameters setting on the computer .
4) This BMS will includes such list :
with one Bluetooth module for Android system only ,4.3Version Above . with wire and connector for the Battery and
Software system of mobile phone will be sent to the buyer .
And we can design and produce Battery protection circuit board in according to client’s demand with certain
reasonable order quantity .
Specification reference for different cells with different chemistry materials :

A.Mobile Phone APP Display and how to set parameters via APP software with the Bluetooth  Communication module as below.

Bluetooth Module
Mobile APP display page for our smart BMS with bluetooth function

APP software display

B .With the PC communication Module as Below ,we can set parameter on PC software like this :


Computer software dispaly

Photo display

Notice of connection  :

A. Firstly ,Please connect bold wires from B- port of the BMS to the negative port of the battery pack .(B- wire should be as short as possible ) ,then connect these voltage detection wires (Please take off these wires from the BMS before connecting these wires to the battery to avoid any connection mistakes )

B. Second ,Please start connect these balance wires to the Battery system from BC0 ,Black thin wire should be connected to the battery negative , and the second wire -white wire BC1 should be connect to the positive port of the first series cell . BC2  should connect to the positive port of second series cell ,and BC3 wire to the third cell’s positive ….connection in this way in order one by one till to the last cell postive port

C. Third . After connection of these balance wires finished , please measure connector voltage from each Neigbouring wires ,the voltage between each neigbouring wires for Li ion battery should be less than 4V and for Lifepo4 Battery should be less than 3.5V ,after confirmation of these wires connection order , you can plug cable connector into the BMS .–wrong connection order will damage our BMS surely . please be carefully with this step .

D. Finally , connect C- wire as negative of charge and discharge , B+ wire as positive of charge and discharge , those wires should

use bold wire to make connection for large current distribution purpose . then please comparing the voltage from the BMS and voltage directly from the Battery to see if they are the same or not . if they are the same value . your connection is correct , otherwise terrible things will happened !!!

Our BMS advantages VS other company’s

For the connection please take a reference to our other link . thanks

shipment
Reminds : We will send the detail connection drawings to the client with this product if client needs and this BMS will includes all necessories connectors with wire to make sure client can connect it easily . please follow up it correctly to avoid of any mistake ,above connection is only for simple explaination purpose .
